京仪股份为大家带来“IEC52&IEC53橡套电缆”相关文章，公司为您提供“IEC52&IEC53橡套电缆”文中涉及的电缆技术参数资料。
安徽京仪橡套电缆报价厂家，IEC52&IEC53
橡套电缆规格：
导体:
群:无1411 - 1类5
核心:无60227 - 5
绝缘材料:
PVC(聚氯乙烯)
无1411 - 2 D型
护套:PVC无S5 1411 - 2类型
包装:
大部分为710塑料线轴或盘绕按要求，京仪股份按客户需求装盘。
技术参数：
PVC材料类型:
连续温度:70°C
绝缘电阻:无60227 - 5
|
型号 |
规范 |
线芯数 |
芯数*横截面 |
颜色顺序 |
|
IEC52-030050-CL |
SANS 60227-5 IEC52 |
3 |
3 x 0.5 mm² |
Yellow/ Green, Blue, Brown |
|
IEC53-030075-CL |
SANS 030075-5 IEC53 |
3 |
3 x 0.75mm² |
Yellow/ Green, Blue, Brown |
|
IEC53-040075-CL |
SANS 60227-5 IEC53 |
4 |
4 x 0.75mm² |
Yellow/ Green, Blue, Brown, Black |
|
IEC53-050075-CL |
SANS 60227-5 IEC 53 |
5 |
5 x 0.75mm² |
Yellow/ Green, Red, Yellow, Blue, Black |
|
IEC53-030100-CL |
SANS 60227-5 IEC 53 |
3 |
3 x 1.0mm² |
Yellow/ Green, Blue, Black |
|
IEC53-040100-CL |
SANS 60227-5 IEC 53 |
4 |
4 x 1.0mm² |
Yellow/ Green, Blue, Brown, Black |
|
IEC53-050100-CL |
SANS 60227-5 IEC 53 |
5 |
5 x 1.0mm² |
Yellow/ Green, Red, Yellow, Blue, Black |
|
IEC53-030150-CL |
SANS 60227-5 IEC 53 |
3 |
3 x 1.5mm² |
Yellow/ Green, Blue, Brown |
|
IEC53-040150-CL |
SANS 60227-5 IEC 53 |
4 |
4 x 1.5mm² |
Yellow/ Green, Blue, Brown, Black |
|
IEC53-050150-CL |
SANS 60227-5 IEC 53 |
5 |
5 x 1.5mm² |
Yellow/ Green, Red, Yellow, Blue, Black |
|
IEC53-030250-CL |
SANS 60227-5 IEC53 |
3 |
3 x 2.5mm² |
Yellow/ Green, Blue, Brown |
|
IEC53-040250-CL |
SANS 60227-5 IEC 53 |
4 |
4 x 2.5mm² |
Yellow/ Green, Blue, Brown, Black |
|
IEC53-050250-CL |
SANS 60227-5 IEC 53 |
5 |
5 x 2.5mm² |
Yellow/ Green, Red, Yellow, Blue, Black |
液位计选型 光伏电缆型号标准
以上是由京仪股份有限公司为大家整理的有关“
IEC52&IEC53橡套电缆”的内容。属于
橡套电缆相关信息。本文地址：http://www.5dd.com.cn/news/hyxw/797.html转载请勿删除，高压电缆、橡套电缆或其它仪表电缆报价资料欢迎您来电索取。
张总：15222906608
